| Specifications |
UMA 8 |
UMA 10 |
UMA 12 |
UMA 16 |
| Working height (A) |
900 cm |
1100 cm |
1300 cm |
1700 cm |
| Platform height - (MAX) (B) |
690 cm |
890 cm |
1090 cm |
1490 cm |
| Platform height - (LOWERED) (C) |
225 cm |
250 cm |
300 cm |
325 cm |
| Platform capacity |
130 kg |
130 kg |
130 kg |
140 kg |
| Platform size |
60 × 60 cm |
65 × 60 cm |
65 × 60 cm |
70 × 65 cm |
Stowed dimension :
width (G)
height (C)
length (D) |
80 cm
225 cm
115 cm |
90 cm
250 cm
125 cm |
100 cm
300 cm
130 cm |
125 cm
325 cm
175 cm |
Tilted back
height (E)
length (F) |
---------- |
---------- |
---------- |
205 × 345 cm |
Outrigger footprint
width × length (J × H) |
137 × 152 cm |
140 × 160 cm |
150 × 170 cm |
300 × 360 cm |
| Weights : AC |
420 kg |
440 kg |
450 kg |
750 kg |
| Weights : DC |
470 kg |
490 kg |
500 kg |
800 kg |
| Power source |
AC 220 V 50 Hz |
DC 12 V 90 amp |
|
|
| Battery charger |
Automatic / 220 V 50 Hz |
Automatic |
